جديد مضخة الخرسانة الثابتة SMCP40

We supply diesel and electric concrete pumps, including trailer pump, mixer pump, concrete distributor, boom pump, crawler pump, mortar pump
SMCP40 is our most popular model of diesel concrete trailer pump, following are specifications

-------------------------------------------------------------------------------------------
Core advantages of SMCP40:
● Portable: Equipped with tires, easy to move
● Easy to operate: Wireless remote control available
● Top-Quality Components: Kawasaki hydraulic pumps (South Korea), Weichai diesel engine, Siemens (Germany) or Omron (Japan) PLC, Schneider electrics (France), Parker seals (US), Manuli main hydraulic hose (Italy), Beijinghuade and Taiwan Northman valve group
● Fully Equipped: 100m pump pipe and spare parts included

-------------------------------------------------------------------------------------------
SMCP40D-10-82R Technical Specifications
● Whole Performance
- Max. theo. concrete output (H/L): 40/26 m³/h
- Max. concrete pumping pressure (H/L): 10/7.6 MPa
- Distribution valve type: S Valve
- Main oil cylinder diameter × stroke: Ф100×1100 mm
- Concrete cylinder diameter × stroke: Ф180×1100 mm
- Hopper capacity × feeding height: 400×1100 L×mm
- Outlet diameter: Ф150 mm
● Power System
- Diesel engine model: Weichai
- Diesel engine power: 82 kW
- Rotate speed: 1800 r/min
● Hydraulic System
- Circuit type: Open circuit
- Hydraulic pump: Kawasaki of Korea
- Displacement: 112 ml/r
- Pumping system pressure: 28 MPa
- Mixing system pressure: 6-8 MPa
- Capacity of oil tank: 370 L
● Other Parameters
- Max conveying distance (vertical/horizontal): 120/500 m
- Max. aggregate diameter: Slick scree 30 mm, Scree 40 mm
- Inside diameter of delivering pipe: Ф125 mm
- Dimensions (length × width × height): 5000×1850×1700 mm
- Total weight: 4500 kg

-------------------------------------------------------------------------------------------
Packing List
● Concrete Pump (SMCP40D): 1 set
● Steel Pipe (Φ125×3m): 30 pcs
● Steel Pipe (Φ125×2m): 2 pcs
● Steel Pipe (Φ125×1m): 2 pcs
● 90°elbow pipe (Φ125): 6 pcs
● 45°elbow pipe (Φ125): 4 pcs
● High pressure rubber hose (Φ125×3m): 1 pc
● Diameter changing pipe (1.5m): 1 pc
● Clamp with rubber Ring (DN125): 43 sets
● Clamp with rubber Ring (DN180): 2 sets
● Hydraulic seal wearing parts: 1 set
● Remote control: 1 pc
● Tools and toolbox: 1 set
● Piston (Φ180): 1 set
● Cleaning Rubber Ball (DN125): 6 pcs

-------------------------------------------------------------------------------------------
Main Configuration
● Diesel engine model: Weichai 82kw of China
● Main hydraulic pump: Kawasaki K3V112 of South Korea
● Valve group: Beijing Huade and Taiwan Northman
● Main Hydraulic hose: Manuli of Italy
● Seals: Parker of US
● Intermediate Relay: Schneider of France
● PLC unit: Omron of Japan OR Siemens of Germany
● Lubrication system: Hydraulic lubricate pump with Double-distributor
● Radiator: Air-cooled
● Circuit type: Double hydraulic open loops with two pumps
